YA-300 model horizontal flowpack machines (high speed wrappers)are manufactured for the customers, aiming high capacity range with multiple product types. It is designed to meet the most demanding requirements in terms of packaging speed, quality sealing, ease of cleaning and high standarts of the internal and structural compenents. Modular cantilevered frame of steel elements. Manufactured and weared by AISI 304 stainless steel components.the machine when guards are openIndividually adjustable film reels provide enhanced film control for tighter packages. Double film reel-holding shaft with servo controlled film extension and brake system. Automatic film splicing system and reel centering control. |
Stainless steel for all parts in contact with product.All mechanical parts are separated from the operating area to respect hygiene conditions.Servo-Assisted operating system, with touch screen controls. Operator interface with touch pad LCD panel for the operation of different programme pages and fault diagnostics. Up to 50 product parameters can be memorized OPERATOR INTERFACE- 10'' touch screen.All safety precautions are taken on the jaw groups, by standartizing the use of safety switches and special covers. Safety guards with switches to stop |
SPECIFICATION | YA-300 |
---|---|
MAX REEL WIDTH | 250 mm |
MAX REEL DIAMETER | 300 mm |
INNER REEL DIAMETER | 70 mm |
SEALING WIDTH | 20 - 35 mm |
LANGITUDINAL SEALING WIDTH | 15 mm |
CUT OFF LENGTH(width 3 jaws) | 130 mm |
CAPACITY(hot healing with 3 jaws) | 100-170 pcs/ min |
CAPACITY(cold healing width 3 jaws) | 250 - 600 dev / dmin |
PACKAGE WIDTH | min 20 mm - max 35 mm |
PACKAGE LENGTH | min 110 mm - max 150 mm |
PACKAGE HEIGHT | min 10 mm - max 25 mm |
WIDTH | 1910 mm |
LENGTH | 8500 mm |
HEIGHT | 2100 mm |
WEIGHT | 1800 kg |
